The ideal asset tracker for trailers or heavy equipment in your fleet. The new G70 comes with a whole host of unique features that will maximize your Return on Investment.


The G70 is equipped with an internal backup battery in case of loss of power or tampering. This device is also exceptionally tough and weatherproof with IP68 proofing.


G70 is fully integrated in Geotab and will allow you to track your assets on the Map tab, leverage rules and alerts, and report on them in the Geotab Dashboard.


BlueArrow’s G70 helps you Understand Your Equipment Utilization, Future-Proof Your Business, Stay Up-to-date On Equipment Maintenance, and Reduce Losses and Prevent Theft.


Features And Benefits

  • Seamless MyGeotab Integration: Take advantage of the extensive MyGeotab feature set
  • Easy to install and conceal with simple hard-wiring
  • 1100mAh backup battery
  • Fully configurable device parameters to fit any tracking application
  • Tough and waterproof IP68 Rated Housing
  • Built-in Battery Life Monitoring
  • 3D Accelerometers for Adaptive Tracking and Accident Detection
  • PTO and Hours Monitoring

Specifications

  • GNSS Module - uBlox EVA-M8Q
  • Constellation - Concurrent GPS / GLONASS / Galileo / BeiDou
  • Tracking Sensitivity: -168 dBM industry-leading tracking performance
  • GNSS Assistance - GNSS almanac and ephemeris data for greater sensitivity and position accuracy
  • Low Noise Amplifier - GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail
  • Connectivity and Input
  • LTE-M / NB-IoT (supports roaming between networks - roaming SIM required) Nordic nRF9160 Modem operates on all major global LTE-M and NB-IoT bands.
  • Input Voltage - 8-36V DC (max)
  • Sleep Current - <10uA
  • Digital Inputs - 3* x Digital Inputs with configurable pull up/pull down 0-48V DC input range
  • Housing
  • Dimensions - 4.92 x 3.15 x 0.98”
  • Ultra-Rugged IP68 Housing
  • Operating Temperature: -30°C to +60°C
